Total space: 1430 m²

Laboratory space: 1100 m²

including 90 m² in the Technology Hall of the Department

including 180 m² at “auf AEG” (EnCN)

including 120 m² at Uferstadt Fürth

Parts of the equipment of our Institute include

(Solution-based) sample preparation

• Aerosol Jet Platform
• Glovebox systems MBraun / Jacomex (GS Glovebox Systems)
• Robotic setup for automatic synthesis and characterization of solvent-preocessed semiconductors
• Spraycoating Setup (Single Head)
• 15 powerful PCs for numerical modelling
• Slot-die-Coater (FMP) (EnCN)
• 4 x ZAA 2300 Zehntner- Filmziehgerät Spezial
• Femtosecondlaser for materials processing , 1040 and 520 nm (HighQ Laser)
• Oerlikon 350G evaporator (Jacomex Glovebox)
• Evaporator  (MBraun Glovebox)
• 3 x SPS Europe Spin150i Spincoater

Materials Characterization

• Scanning electron microscope with CL and EDX  (JEOL, JSM7610F)
• X-ray diffractometer (Panalytical)
• Particle size analyzer (Coulter LS100)
• Dynamic Light Scattering System (Nanoflex, Microtrack)
• UV-Vis absorption spectrometer, 190 – 3000 nm (Perkin Elmer Lambda 950)
• Photoluminescence setup, detection 300 – 1600 nm, excitation wavelengths 325, 375, 488, 514, 632, and 975 nm
• Photoinduced Absorption Setup (pump 532 and 785 nm, Probe 500 – 1700 nm)
• Flourometer FP-8500 (Jasco, excitation 200 – 600 nm, detection 300 – 850 nm)
• Timeresolved fluorometer (PicoQuant FL300)
• Kelvin-Probe with surface Photovoltage Spectroscopy option
• Contact angle measurement OCA 20
• AFM Mikcroscope ( NT-MDT )
• Optical Microscope (Keyence)
• Rheometer HAAKE RheoStress 600
• I-V-testing systems BoTest
• Reflectometer and film thickness analyzer (Filmetrics)
• Transient photocurrent Setup (CELIV)
• FTIR Spektrometer (Bruker, Vertex 70)
• Optical In Situ Film Drying Analyzer
• Confocal microscope NanoFocus µsurf explorer
• Luminescence microscope with a 532 nm laser (Photon etc.)
• Accelerated degradation laboratory for solar cells
• Calorimeter  Waters DSC Q1000 Auto MDSC
• Oriel Sol1A 6×6 1.0KW Solar Simulator
• Wavelabs LED solar simulator  with I-V measurement setup
• KLA Tencor D100 – layer thickness measurement
